Model No. |
HD1.25 |
HD1.53 |
HD1.66 |
HD1.86 |
HD2 |
Module |
Pixel Pitch (mm) |
P1.25 |
P1.53 |
P1.667 |
P1.86 |
P2 |
LED Type |
SMD 1010 |
SMD 1212 |
SMD 1212 |
SMD 1515 |
SMD 1515 |
Module Dimension (W*H) (mm) |
320x 160 |
320x 160 |
320x 160 |
320x 160 |
320x 160 |
Module Resolution (W*H) (Pixel) |
256x 128 |
208x 104 |
192x 96 |
172x 86 |
160x 80 |
Pixel Density (pixel/㎡) |
640000 |
422500 |
360000 |
288906 |
250000 |
Scan Mode (S) |
64 |
52 |
48 |
43 |
32 |
Cabinet |
Cabinet Dimension (W*H) (mm) |
640x 480 |
640x 480 |
640x 480 |
640x 480 |
640x 480 |
Cabinet Resolution (W*H) (Pixel) |
512x 384 |
416x 312 |
384x 288 |
344x 258 |
320x 240 |
Cabinet Material |
Diecasting Aluminum |
Cabinet Weight (Kg) |
6.8 |
6.8 |
6.8 |
6.8 |
6.8 |
Display |
Best Viewing Distance (m) |
1.25 |
1.53 |
1.66 |
1.86 |
2 |
Brightness (nits) |
900 |
Ingress Protection (Front/Rear) |
IP31 |
Viewing Angle |
H: 160° V: 160° |
Color Temperature (K) |
3200~ 9500 |
Gray Level (bit) |
14 |
Max Power Consumption (W/㎡) |
600 |
Average Power Consumption (W/㎡) |
250 |
Refresh Rate (Hz) |
3840 |
Maintenance Method |
Front Maintenance |
Operating Temperature |
-20°~ 60° |
Operating Humidity |
10%~ 95% RH |
Input Voltage |
AC110~ 260V 50/ 60Hz |
MTBF (Hours) |
50000 |
LifeTime (Hours) |
100000 |
